Maximum Operating Pressure (bar): 700
Capacity Class (tonnage): 100
Maximum Cylinder Capacity Advance (kN): 1002
Stroke (mm): 50
Collapsed Height A (mm): 202
Extended Height B (mm): 252
Return Type: Double-Acting, Hydraulic Return
Plunger Type: Solid
Material: Steel
Cylinder Effective Area Advance (cm2 ): 143,1
Oil Capacity Advance (cm3 ): 716
Oil Capacity Retract (cm3 ): 361
Sideload Resistance of Maximum Capacity (percentage): 10%
Surface Treatment: Nitride
Coupler: CR400 Coupler
Weight (kg): 34
